Meet the Turbo-Beaver at ½ the price
Over the last 7 years, Aerotek Aviation has built various types of aircraft sporting its PT6 firewall forward package for experimental aircraft. Aerotek his also well known for winning multiple awards for Best in Class at the 2 major Air Show in North America, S & F and OSH with the Turbine Murphy Moose and with our New Turbo-Grizzly. In the last year, we became also an
approved shop to convert the venerable Piston DHC2 Beaver in PT6 Turbo Beaver.
The main idea behind for the Turbo-Grizzly was to compete with the Turbo-Beaver in terms of
useful load, performance, structural strength but at half the price. If you are a private owner and doesn’t need a certified aircraft for commercial operation, the Turbo-Grizzly is the perfect aircraft for you.
The Grizzly is born from the DHC2 Beaver. We have used a mix of ideas from the Lockheed AL
60 and the DHC2 Beaver structure to create this experimental class of aircraft and has been built
FAR 23 regulations in mind. Each Turbo-Grizzly is meticulously crafted to meet or exceed original
Beaver specifications and equipments. You are invited to view all aspects of your new Grizzly
during construction.
In landplane form, our Turbo-Grizzly operates from un-surfaced ground strips or forest clearings of three hundred metres (1,000 feet) in length. With fuel reserves, operating under Visual Flight Rules (VFR), it carries a load of about half a ton on practical stages for nearly 1,000 kilometres (about 600 statute miles). It has an empty weight of 2850 on wheels and a gross of 5500 pounds. Its amphibious version has an empty weight of 3540. Sporting the New Adventures floats amphibious 5500, you will still have 900 pounds of useful load with 4 hours of fuel and will cruise at 130 knts TAS at 3500 feet. 2 large cargo doors on each side and a pilot door will provide you with all loading capabilities required. The Turbo-Grizzly is versatile and may be adapted for agricultural spraying, parajumpjng or ski operation. Designed with simplicity of maintenance in mind, low cost operation and IFR equipped with full EFIS synthetic 3D vision displays, the Turbo- Grizzly is simply the most versatile and low cost Turbine Bush plane or heavy hauler available on the market. Add in the legendary reliability and safety of the PT6 Turbine, reduced work load for the pilot when flying with a turbine engine, 5000 hours TBO and you have an unbeatable
package.
Just imagine the ease of docking or beaching with a reversing prop!
Standard Specifications (Proposed Items – Customized to fit your needs)
Custom Leather 6-7 Seat interior
Custom Interior
Tinted Windows
Strobe System
New Adventure 5500 Amphib Floats
Gear Advisory system
Custom Instrument panel with Dual GRT Avionics 3D Synthetic vision displays
Auto-Pilot coupled with GRT avionics with fully integrated GPS + approaches, ILS, VOR, GPS
Garmin SL 30 Nav-Com
Garmin SL40 Com
Garmin 496 with weather and XM radio
Custom High Quality paint choose by owner
POWER PLANT: PT6-20 (T74-CP700) 550 SHP
PROPELLER: HARTZELL 93 INCH, 3 BLADED, CONSTANT SPEED, FULL FEATHERING, REVERSIBLE
FLOATS: ALL ALUMINIUM 5500 BUYOANCY. WIPLINE STYLE AMPHIBIOUS
|
|
WINGSPAN | 46,5 FEET |
WING LOADING | 20,4 LB/SQ FEET |
FUEL CAPACITY | 180 US/GAL |
OIL CAPACITY | 14 QT |
|
|
MAX GROSS AT TAKE-OFF | 5500 |
EMPTY WHEIGHT ON WHEELS | 2850 |
EMPTY WEIGHT ON AMPHIBS | 3600 |
|
|
TAKE OFF DISTANCE ON WHEELS | 850 FT |
OVER 50 FOOT OBSTACLE | 1500 FT |
WATER RUN (AVERAGE on Amphibs) | 10-15 SECONDS |
|
|
CLIMB PERFORMANCE @ ISA AT GROSS @ 550 SHP | 1200 FPM |
STALL FULL FLAPS | 52 KNTS |
STALL CLEAN | 65 KNTS |
|
|
IAS @ GROSS AT SL (ISA) @ 75% (amphibs) | 125 KNTS |
TAS @ GROSS AT 3500 FEET @ 75% (amphibs) | 130 KNTS |
TAS @ GROSS AT 10 000 FEET @ 75% (amphibs) | 145 KNTS |
Add 20 KNTS on Wheels at reduced power | |
|
|
NORMAL CRUISE SPEED | 140 KNTS |
MAX MANOEUVERING SPEED | 130 KNTS |
NEVER EXCEED | 165 KNTS |
|
|
WHITE ARC | 52-100 KNTS |
GREEN ARC | 65-130 KNTS |
RED LINE (vne) | 165 KNTS |
|
